Discharging Mud Rubber Hose

Inner rubber layer: black oil-resistant synthetic rubber.

Reinforcement layer: a layer of high-strength steel wire weave ( 1W/B )

Outer rubber layer: black oil-resistant, corrosion-resistant, and abrasion-resistant synthetic rubber with the appearance of the cloth pattern surface.

Temperature range: -40 ℃ to +100 ℃

No need to peel the outer rubber for these mud drainage hose buckle joints

Dia. of Through 5	Inner Dia.		Outer dia. of reinforcement layer	Outer dia. of hose	Working Pressure		Brust Pressure		Min. bending radius	Weight	Length
	inch	mm	mm	mm	MPa	psi	MPa	psi	mm	kg/m	m
5	3-16	4.8	9.5	11.8	25.0	3630	100.0	14280	89	0.19	50/100
6	1/4	6.4	11.1	13.4	22.5	3270	90.0	12840	102	0.21	50/100
8	5/16	7.9	12.7	15.0	21.5	3120	85.0	12280	114	0.24	50/100
10	3/8	9.5	15.1	17.4	18.0	2614	72.0	10280	127	0.33	50/100
13	1/2	12.7	18.3	20.6	16.0	2320	64.0	9180	178	0.41	50/100
16	5/8	15.9	21.4	23.7	13.0	1890	52.0	7420	203	0.45	50/100
19	3/4	19.0	25.4	27.7	10.5	1530	42.0	6000	241	0.58	50/100
25	1	25.4	33.3	35.6	8.8	1280	35.0	5020	305	0.88	50
32	1 1/4	31.8	40.5	43.5	6.3	920	25.0	3600	419	1.23	20 to 60
38	1 1/2	38.1	46.8	50.6	5.0	730	20.0	2860	508	1.51	20 to 60
51	2	50.8	60.2	64.0	4.0	580	16.0	2280	635	1.97	20 to 60
