Backhoe dredger applicable Industries
Farms, Construction works , Other, Sand, gold, diamond, mud, gravel, rock dredging, Sand excavating, river dredging, Desilting, reclamation for channel, Land, island, sea port, air port construction, Inland waterway dredging, Lake, pool, ditches, reservoir, sea dredging.
LOA
Bucket Capacity
Depth
Dredging Depth
Basic parameters of Backhoe dredger
|
LOA |
30.00 m |
Ship length |
28.00m |
|
Length of load waterline |
29.00m |
Beam |
9.60m |
|
Max Beam |
9.75m |
Depth |
2.20m |
|
Max Height |
3.40m |
Light draught |
1.242m |
|
Load draft |
1.300m |
Full load displacement |
322.753 t |
|
Light displacement |
260.696t |
Hull materials |
Steel |
|
Number of watertight transverse bulkheads |
9 |
Structure Type |
Mixed skeleton type |
|
Number of cargo holds |
0 |
Main Engine Model |
SC15G110CA2 |
| Main Engine Type |
Diesel engine |
Main Engine Machine Number |
G9235001114 |
|
Rated power |
73 |
Rated speed |
1500 |
|
Propeller Type |
Fixed Type |
Propeller Material |
Cast Steel |
| Propeller Diameter(mm) | 1150 |
Shafting Diameter(mm) |
105 |
|
power generator Model No |
TFS-H50 |
power generator Qty | 1 |
|
Rated Power(kW) |
50 |
Rated Speed(r/min) |
1500 |
|
Current |
AC90.20A |
Rated Voltage(V) |
400.00 |
|
Model No of prime mover |
WR4105ZCD2 |
Quantity |
1 |
|
Rated power(kW) |
58 |
Rated speed(r/min) |
1500 |
|
battery capacity(Ah) |
400 |
battery application |
Emergency power supply |
|
Emergency power supply |
2 |
Number of emergency distribution boards |
1 |
