comparison of Ship Crane

Lifting weight	6000kg
Lifting height	22m
Length of lifting arm	*5m5**
Winches	W15D
Reducer	WC126
Size	*7.52.1m**
Power of motor	11kW
Lifting speed	45m/min
Rotation speed	28r/min
Power selection	Diesel generator

Marine crane configuration.

◆ Hydraulic system: full hydraulic servo control operating system, integrated hydraulic valve group single group independent operation (can realize compound action)

◆ Slewing system: 50 manganese calcined track flint tempered slewing support, four-way central slewing device (can achieve 360° continuous unlimited rotation)

◆ Winch system: 1.5t/2t hydraulic winch with automatic brake system

◆ Boom system: 8-sided boom 6.2m X 3/4 sections (fully automatic hydraulic cylinder telescopic)

◆ Expandable configuration: the hoisting system can be expanded with oil and electricity (11KW motor independent pump source)

The so-called ship crane refers to the ship itself equipped with lifting equipment, while the floating crane is a special water lifting equipment.

When the lifting force of the ship crane is not enough, a floating crane with greater lifting force is needed to complete the loading and unloading task.
