Name: China Electric Submersible Sand Slurry Dredger Pump Suppliers, Manufacturers - Factory Direct Price - TRODAT
Brand: TRODAT
SKU: 162001721

TYPE	Voltage/Freq. V/Hz	Discharge Bore(mm)	Head (m)	Capacity (m³/h)	Max. of Solid(mm)	Power (Kw)	Speed (r/min)	Weight (kg)
TSP-3701-12P5	690/50	550	40	3700	120	900	490	10800
TSP-3702-12P5	690/50	550	21	3700	120	550	490	8800
TSP-901-12P5	380/50	300	16	900	120	100	490	3500
TSP-0501-4P6	460/60	100	52	50	20	30	1740	550
TSP-5001-14P5	1000/50	600	27	5700	120	950	421	33000
TSP-6501-16P6	3300/60	650	35	7800	120	1500	442	40000
TSP-9.501-6P6	460/60	250	62	950	120	350	1176	5000
TSP-2001-8P6	460/60	400	62	2000	120	1000	888	8000

Working Conditions

Medium: water (PH: 6.5-8.5)

Medium temperature: <25C or 90'C3. Sand content (by weight):< 30%

Max. Diameter of solid: 1 20mm

Ambient temperature: -25'C~+45'C

Relative humidity: not over < 97%

Enclosure protection: IP68

Power supply: 380-6300V, 50Hz/60HZ, 3Ph9. Motor power:< 2000kW

Capacity: Q < 1 5000m'/h

Head: H < 50m

Submersible depth: < 150m

tsp-7
